Signal decoding of DMX512, single PC supports to connecting with several USB-DMX decoding, it is stable in output.

USB-BOX has the standard 3xDMX512 output( 1536 dmx channels ).

Connect to Ethernet, over WIFI, can control remotely from WINDOWS,IOS,Android tablet or smartphone.

Support the model of PC working or off-line working, equip with SD card memory of memory function,be capable of independently working without computer.

Set up 3D stage in computer,to achieve real-time display effect:3D effect of computer is synchronous with on-site lighting.

Audio is synchronous with lighting effect to produce music show,can drag and drop,remove and extend in time scale of AC to arrange the lighting time of start and end in Timelines

Without computer,can supports 3 DMX output.

Set up your own luminaires data or modify existing luminaires data,includes all lighting effect(colors,gobos,gobos rotation,prism ect..).

The built-in icons with intuitive effect and app,it is convenient to use by mouse.

AVI export of 3D lighting effect.

Supports operating system:  Windows 7 32 bit /Windows 7 64 bit /Windows 10 64 bit.

A built-in program called out to edit when Independence Model edits procedure.

Object shape can be saw when 3D stage calls out object.

Processor frequency: 800Mhz.

RAM: 256Mb.

It has Video Capture Card with 32 Mb(RAM) what can support Microsoft Direct 3D.

800x600 pixel screen.

Windows 10 can be run.

Processor frequency: 2Ghz.

RAM: 8G.

It has Video Capture Card with 128 Mb(RAM) what can support Microsoft Direct 3D.

1280x1028 pixel screen.

Request of external power supply of USB-DMX decoder when it is off-line.

Voltage: 5V DC.

Current: ge300mA
